The linear bearing cage is an essential component of a linear rolling bearing built with the use of linear guides. The main task of the bearing cage is to hold the rolling elements inside the bearing on the guide's raceways in the correct operating position.
Angular double-row bearing cages with bearing needles
Manufactured from profiles of light metals - aluminium (Al), brass (Ms) or steel (F)
High precision and strength at low deadweight (aluminium)
Destined for heavy-duty working conditions at high loads and accelerations
Working temperature up to 150°C
HW looks similar to H...ZW, however, cage sides are symmetrically bent at the right angle towards each other
Applicable areas include also linear guides of the types
Technical drawing of HW bearing cages
Dimension table of HW bearing cages
Needle
diameter
Ø
Type/symbol
Dimensions
Load capacity *
A
DW
LW
t
e
LK
max
C
[N]
CO
[N]
2
HW 10
11
2
4.8
4
3
2 000
21 400
68 700
2
HW 15
14
2
6.8
4.5
3.5
2 000
26 200
88 900
2
HW 16
16
2
8.8
3.8
2.8
2 000
36 900
138 100
2.5
HW 20
19
2.5
9.8
5.5
4
2 000
40 300
133 500
3
HW 25
25
3
13.8
6
4.5
2 000
62 900
209 400
3.5
HW 30
31
3.5
17.8
7
5
2 000
82 700
268 700
3.5
FFW 3,5
17.25
3.5
7.8
8
5
2 000
38 700
101 200
*) - Load capacity for the theoretical length of the cage of 100 mm with the thrust force "F" in accordance to the drawing.
- The load capacity is calculated for guides with hardness of 60 +/- 2 HRc oand surface roughness of Ra<0.4.
- Load capacity of bearing cages is calculated on the basis of number of bearing needles mounted in the cage
- Length tolerance LK +0/-t
Weight table of HW bearing cages
Table for weight values of bearing cages
(for the length of Lk=1000 mm) [g]
Type/symbol
Aluminium
Stel
Brass
HW 10
105
219
230
HW 15
138
289
306
HW 16
190
-
390
HW 20
239
471
499
HW 25
408
756
798
HW 30
598
1117
1178
FFW 3.5
-
-
711
AlAluminium
MsBrass
FSteel
